SP2T PIN Diode Switch

Rev. V1

MSW200x-200

3

3

M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.

Visit www.macom.com for additional data sheets and product information.

For further information and support please visit:

https://www.macom.com/support

DS-xxxxxxx

3

Parameter

Test Conditions

Units

Min.

Typ.

Max.

Frequency

—

GHz

2

—

6

TX-Ant Insertion Loss

Condition 1

dB

—

0.6

0.7

Ant-RX Insertion Loss

Condition 2

dB

—

0.9

1.0

TX-Ant Return Loss

Condition 1

dB

13

15

—

Ant-RX Return Loss

Condition 2

dB

11

13

—

TX-RX Isolation

Condition 1

dB

32

34

—

RX-TX Isolation

Condition 2

dB

11

13

—

Condition 1, 1.5:1 Source & Load VSWR

dBm

—

—

50

Condition 2, 1.5:1 Source & Load VSWR

dBm

—

—

43

Condition 1, 10 µs Pulse Width, 1% Duty Cycle,

1.5:1 Source & Load VSWR (IL)

dBm

—

—

57

10% - 90% RF Voltage

µs

—

1.0

1.5

Input IP3

F1 = 500 MHz, F2 = 510 MHz, P1=P2=40 dBm

dBm

60

65

—

1. PIN diode DC reverse voltage to maintain high resistance in the OFF PIN diode is determined by RF frequency, incident power, and VSWR

as well as by the characteristics of the diode. The minimum reverse bias voltage values are provided in this datasheet. The input signal

level applied for small signal testing is approximately 0 dBm.

2. Switching time (50% TTL - 10/90% RF Voltage) is a function of the PIN diode driver performance as well as the characteristics of the

diode. An RC “current spiking network” is used on the driver output to provide a transient current to rapidly remove stored charge from the

PIN diode. Typical component values are: R = 50 to 220 Ω and C = 470 to 1,000 pF. MACOMs MPD2T28125-700 is the recommended PIN

diode driver to interface with the MSW2000-200, MSW2001-200 SP2T and MSW2002-200 switches. Its data sheet is available.

Bias State Conditions:

Transmit State

(TX - ANT in low insertion loss state):

a. B1: -100 mA

b. B2: +100 mA

c. B3: -25 mA, +28 V

d. B4: +25 mA

Small Signal Receive State

(ANT - RX in low insertion loss state):

a. B1: +28 V

b. B2: +100 mA

c. B3: -100 mA, 0 V

d. B4: +28 V
