3.0 System Wake-Up Control (SWC) (Continued)
90
www.national.com
3.4.4
Wake-Up Events Enable Register (WK_EN0)
This register is set to 00h on power-up of VPP or software reset. Detected wake-up events that are enabled activate the
PWUREQ signal.
Location:
Offset 02h
Type:
R/W
Bit
76543210
Name
Module IRQ
Event
Enable
Software
Event
Enable
GPIO Event
Enable
CEIR
Event
Enable
Mouse
Event
Enable
KBD
Event
Enable
RI2
Event
Enable
RI1
Event
Enable
Reset
00000000
Bit
Description
7
Module IRQ Event Enable
0: Disabled (default)
1: Enabled
6
Software Event Enable
0: Disabled (default)
1: Enabled
5
GPIO Event Enable
0: Disabled (default)
1: Enabled
4
CEIR Event Enable
0: Disabled (default)
1: Enabled
3
Mouse Event Enable
0: Disabled (default)
1: Enabled
2
KBD Event Enable
0: Disabled (default)
1: Enabled
1
RI2 Event Enable
0: Disabled (default)
1: Enabled
0
RI1 Event Enable
0: Disabled (default)
1: Enabled
