Electrical characteristics
LDF
8/33
DocID025502 Rev 2
Symbol
Parameter
Test conditions
Min.
Typ.
Max.
Unit
SVR
Supply voltage
rejection
VIN = 4.5 V +/- 0.5 VRIPPLE
f = 120 Hz
VOUT = 3.3 V
60
dB
VIN = 4.5 V +/- 0.5 VRIPPLE
f = 120 Hz to 100 kHz
VOUT = 3.3 V
45
eN
Output noise voltage
Bw = 10 Hz to 100 kHz,
ILOAD = 100 mA
COUT
= 2.2 μF
45
μVRMS
/VOUT
TSHDN
Thermal shutdown
170
°C
Hysteresis
10
Notes:
(1) For VOUT < 1.6 V; VIN = 2.6 V.
(2) Dropout voltage is the input-to-output voltage difference at which the output voltage is 100 mV below its
nominal value. This specification does not apply to output voltages below 1.6 V.
