34 | Keysight | Infiniium Z-Series Oscilloscopes - Data Sheet

Specifications

Vertical

Z204A

Z254A

Z334A

Z504A

Z592A

Z594A

Z632A

Z634A

Typical analog bandwidth (3 dB)

20 GHz

25 GHz

33 GHz

50 GHz

59 GHz

59 GHz

63 GHz

63 GHz

Analog bandwidth (3 dB) *

20 GHz

25 GHz

32 GHz

50 GHz

59 GHz

59 GHz

62 GHz

62 GHz

1-channel sample rate

80 GSa/s

80 GSa/s

80 GSa/s

160 GSa/s 160 GSa/s 160 GSa/s 160 GSa/s 160 GSa/s

2-channel sample rate

80 GSa/s

80 GSa/s

80 GSa/s

160 GSa/s 80 GSa/s

160 GSa/s 80 GSa/s

160 GSa/s

4-channel sample rate

80 GSa/s

80 GSa/s

80 GSa/s

80 GSa/s

—

80 GSa/s

—

80 GSa/s

Rise time/fall time

Z204A

Z254A

Z334A

Z504A

Z592A

Z594A

Z632A

Z634A

22.0 ps

17.6 ps

13.3 ps

8.8 ps

7.5 ps

7.5 ps

7.0 ps

7.0 ps

15.6 ps

12.4 ps

9.4 ps

6.2 ps

5.3 ps

5.3 ps

4.9 ps

4.9 ps

50 Ω, ± 3%

1 mV/div to 1 V/div

Input coupling

DC

8 bits, ≥ 12 bits with averaging

Channel to channel isolation (any two channels

with equal V/div settings)

RealEdge (1.85 mm) channels

DC to 40 GHz: 70 dB

40 GHz to BW: 60 dB

Standard (3.5 mm) channels

DC to BW: 70 dB

DC gain accuracy *

± 2% of full scale at full resolution channel scale (± 2.5% for 5 mV/div)

Maximum input voltage

± 5 V for steady state and transient measurements

RMS noise floor (scope only)

Z204A

Z254A

Z334A

Z504A

Z594A, Z592A Z634A, Z632A

Volts/div

10 mV

0.41 mV (rms)

0.48 mV (rms)

0.60 mV (rms)

0.90 mV (rms)

0.96 mV (rms)

1.0 mV (rms)

50 mV

1.46 mV (rms)

1.7 mV (rms)

2.00 mV (rms)

2.90 mV (rms)

3.15 mV (rms)

3.3 mV (rms)

100 mV

2.90 mV (rms) 3.3 mV (rms)

3.90 mV (rms)

5.70 mV (rms)

6.2 mV (rms)

6.4 mV (rms)

1 V

28.6 mV (rms) 32.5 mV (rms)

38.1 mV (rms)

56.7 mV (rms)

60 mV (rms)

63 mV (rms)

*

Denotes warranted specifications, all others are typical. Specifications are valid after a 30-minute warm up period, and ± 5 °C from annual calibration

temperature.

1. Vertical resolution for 8 bits = 0.4% of full scale, for 12 bits = 0.024% of full scale.

2. Full scale is defined as 8 vertical divisions. Magnification is used below 7.5 mV/div. Below 7.5 mV/div, full-scale is defined as 60 mV/div. The major scale

settings are 5 mV, 10 mV, 20 mV, 50 mV, 100 mV, 200 mV, 500 mV, and 1 V.

3. Input impedance is valid when V/div scaling is adjusted to show all waveform vertical values within scope display.

4. Rise time calculated by using 0.44/BW for (10 to 90%) rise time.

5. Rise time calculated by using 0.31/BW for (20 to 80%) rise time.

Offset range

Vertical sensitivity

Available offset

Available offset (oscilloscope with

N7010A voltage termination adapter)

1 to 49 mV/div

± 0.4 V

± 4 V

50 to 79 mV/div

± 0.7 V

± 4 V

80 to 134 mV/div

± 1.2 V

± 4 V

135 to 239 mV/div

± 2.2 V

± 4 V

240 mV/div to 1 V/div

± 4.0 V

± 4 V

Offset accuracy *

≤ 3.5 V: ± (2% of channel offset + 1% of full scale) + 1 mV

> 3.5 V: ± (2% of channel offset + 1% of full scale)

Dynamic range

± 4 div from center screen

DC voltage measurement accuracy

Dual cursor: ± [(DC gain accuracy) + (resolution)]

Single cursor: ± [(DC gain accuracy) + (offset accuracy) + (resolution/2)]
