37 | Keysight | Infiniium Z-Series Oscilloscopes - Data Sheet

Acquisition

Z204A, Z254A, Z334A

Z592A, Z632A

Z504A, Z594A, Z634A

Maximum real-time sample rate

1 channels

80 GSa/s

160 GSa/s

2 channels

80 GSa/s

160 GSa/s

4 channels

80 GSa/s

—

80 GSa/s

Memory depth per channel

4 channels (Z204A, Z254A, Z334A, Z504A, Z594A,

Z634A) and 2 channels (Z592A, Z632A)

2 channels (Z204A, Z254A, Z334A, Z504A,

Z594A, Z634A) and 1 channel (Z592A,

Z632A)

Standard

50 Mpts

100 Mpts

Option 100

100 Mpts (standard on DSA models)

200 Mpts (standard on DSA models)

Option 200

200 Mpts

400 Mpts

Option 500

500 Mpts

1 Gpt

Option 01G

1 Gpt

Option 02G

2 Gpts

Maximum acquired time at highest real-time resolution

Real-time resolution

80 GSa/s

160 GSa/s

Resolution

12.5 ps

6.25 ps

Standard (20 M)

0.25 ms

0.125 ms

Option 50 M

0.625 ms

0.3125 ms

Option 100

1.25 ms

0.625 ms

Option 200

2.5 ms

1.25 ms

Option 500

6.25 ms

3.125 ms

Option 01G

12.5 ms

6.25 ms

Option 02G

25 ms

12.5 ms

Sampling modes

Real-time

Successive single shot acquisitions

Real-time with averaging

Selectable from 2 to 65534 (Up to 200,000 with function)

Real-time with peak detect

80 GSa/s (Unavailable on RealEdge channels)

Real-time with hi resolution

Real-time boxcar averaging reduces random noise and increases resolution (unavailable on RealEdge

channels)

Equivalent time

Resoution 338 fs

Gaussian magnitude, linear phase

Slower filter roll off while maintaining linear phase

Roll mode

Scrolls sequential waveform points across the display in a right-to-left rolling motion. Works at sample rates

up to 10 MSa/s with a maximum record length of 40 Mpts

Segmented memory

Captures bursting signals at max sample rate without consuming memory during periods of inactivity

Maximum time between triggers is 562,950 seconds

Re-arm time: 2.5 µs

Specifications (Continued)

Filters

Sin(x)/x Interpolation

On/off selectable FIR digital filter (2x, 4x, 8x, 16x settings). Digital signal processing adds points between

acquired data points to enhance measurement accuracy and waveform display

Memory depth:

20 M

50 M

100 M

200 M

500 M

1 G

2 G

Max # of segments: 4096

8192

16384

32768

65536

131072
