Hardware trigger

Sensitivity

Internal low: 2.0 div p-p 0 to 22 GHz

Internal high: 0.3 div p-p 0 to 18 GHz, 1.0 div p-p 0 to 22 GHz

Edge trigger bandwidth (Ch1 to Ch4)

> 20 GHz

Edge trigger bandwidth (AUX)

400 MHz

Minimum pulse width trigger

Hardware

250 ps

Software (InfiniiScan)

40 ps

Level range

Internal

± 4 div from center screen or ± 4 V, whichever is smaller

Auxiliary

± 5 V, also limit input signal to ± 5 V

Sweep modes

Auto, triggered, single

170 fs rms

Trigger sources

Channel 1, Channel 2, Channel 3, Channel 4

Trigger modes

Edge

Triggers on a specified slope (rising, falling or alternating between rising and falling) and voltage level on any

channel or auxiliary trigger. Edge trigger bandwidth is > 20 GHz

Edge transition

Trigger on rising or falling edges that cross two voltage levels in > or < the amount of time specified. Edge

transition setting from 250 ps

Edge then edge (Time)

The trigger is qualified by an edge. After a specified time delay between 10 ns to 10 s, a rising or falling edge on

any one selected input will generate the trigger

Edge then edge (Event)

The trigger is qualified by an edge. After a specified delay between 1 to 16,000,000 rising or falling edges,

another rising or falling edge on any one selected input will generate the trigger

Glitch

Triggers on glitches narrower than the other pulses in your waveform by specifying a width less than your

narrowest pulse and a polarity. Triggers on glitches as narrow as 125 ps. Glitch range settings: < 250 ps to < 10 s

Pulse width

Trigger on a pulse that is wider or narrower than the other pulses in your waveform by specifying a pulse width and

a polarity. Triggers on pulse widths as narrow as 125 ps. Pulse width range settings 250 ps to 10 s. Trigger point

can be “end of pulse” or “time out”

Runt

Triggers on a pulse that crosses one threshold but fails to cross a second threshold before crossing the first again.

Can be time qualified with minimum setting of 250 ps

1. Denotes warranted specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and ± 5 °C from firmware calibration

temperature.

2. Internal edge trigger mode with JitterFree correction. Value depends on scope settings and trigger signal characteristics, and is equal to Time Interval Error

value expressed in the formula above using the minimum Time Scale Accuracy value.

3. Value shown represents typical Display jitter for DSOZ334A at 100 mV/div triggering on 500 mVpp 16 GHz sin wave signal.

4. Sample rate at maximum. Noise and slew rate determined at fixed-voltage trigger threshold, near middle of signal. Displayed signal not vertically clipped.

Specifications (Continued)
