Cool-Power® ZVS Switching Regulators
Rev 1.5
Page 13 of 41
03/2018
PI352x-00
Figure 19 — Transient Response: 50% to 100% load, at 1A/µs.
Nominal Line, Nominal Trim,
COUT = 8 x 100µF Ceramic
Figure 23 — Output Voltage Ripple: Nominal Line, Nominal Trim,
50% load, COUT = 8 x 100µF Ceramic
Figure 22 — Output Short Circuit, Nominal Line
Figure 20 — Output Voltage Ripple: Nominal Line, Nominal Trim,
100% load, COUT = 8 x 100µF Ceramic
Figure 21 — Switching Frequency vs. Load, Nominal Trim
Figure 24 — System Thermal Specified Operating Area: Max IOUT
at Nominal Trim vs. temperature at locations noted
PI3523-00 (3.3VOUT) Electrical Characteristics (Cont.)
0
5
10
15
20
25
040
20
Temperature of Isothermal PCB (ºC)
60
80
100
120
140
Notes:
1. SiP is based on VS1 and VIN paths only.
2. Inductor is based on two leads and base
with inclusion of GEL 30 interface
resistance (0.15mm thick; 3.5W/m-K
thermal conductivity).
Load Current (A)
30V
IN
48V
IN
60V
IN
0
100
200
300
400
500
600
1.1
3.3
5.5
7.7
9.9
12.1 14.3 16.5 18.7 20.9
