Cool-Power® ZVS Switching Regulators
Rev 1.5
Page 20 of 41
03/2018
PI352x-00
Figure 48 — Transient Response: 50% to 100% load, at 1A/µs.
Nominal Line, Nominal Trim,
COUT = 12 x 47µF Ceramic
Figure 52 — Output Voltage Ripple: Nominal Line, Nominal Trim,
50% load, COUT = 12 x 47µF Ceramic
Figure 51 — Output Short Circuit, Nominal Line
Figure 49 — Output Voltage Ripple: Nominal Line, Nominal Trim,
100% load, COUT = 12 x 47µF Ceramic
Figure 50 — Switching Frequency vs. Load, Nominal Trim
Figure 53 — System Thermal Specified Operating Area: Max IOUT
at Nominal Trim vs. temperature at locations noted
PI3525-00 (5VOUT) Electrical Characteristics (Cont.)
0
4
2
6
8
10
12
20
22
14
16
18
25
50
Temperature of Isothermal SiP VIN and VS1 pins,
and PCB at Inductor (ºC)
75
100125
Note:
SiP is based on VIN and VS1 paths
only. Inductor is based on base with
inclusion of GEL 30 interface
resistance (0.15mm thick; 3.5W/m-K
thermal conductivity), and all leads.
Load Current (A)
30V
IN
48V
IN
60V
IN
300
325
350
375
400
425
450
475
500
525
550
575
600
625
02
46
8101214161820
