ADRF6614
Data Sheet
Rev. 0 | Page 46 of 61
Bits
Bit Name
Settings
Description
Reset
Access
6
VCOBUF_LDO_EN
VCO buffer LDO enable.
0x0
RW
5
REF_BUF_EN
Reference buffer enable.
0x0
RW
4
VCO_EN
Power up VCOs.
0x0
RW
3
DIV_EN
Power up dividers.
0x0
RW
2
CP_EN
Power up charge pump.
0x0
RW
1
VCO_LDO_EN
Power up VCO LDO.
0x0
RW
0
LDO_3P3_EN
Power up 3.3 V LDO.
0x0
RW
Address: 0x02, Reset: 0x0058, Name: INT_DIV
Table 29. Bit Descriptions for INT_DIV
Bits
Bit Name
Settings
Description
Reset
Access
15
DIV_MODE
Set fractional/integer mode.
0x0
RW
0
Fractional.
1
Integer.
[14:0]
INT_DIV
Set divider INT value.
0x58
RW
Address: 0x03, Reset: 0x0250, Name: FRAC_DIV
Table 30. Bit Descriptions for FRAC_DIV
Bits
Bit Name
Settings
Description
Reset
Access
[15:0]
FRAC_DIV
Set divider FRAC value.
0x250
RW
Address: 0x04, Reset: 0x0600, Name: MOD_DIV
Table 31. Bit Descriptions for MOD_DIV
Bits
Bit Name
Settings
Description
Reset
Access
[15:0]
MOD_DIV
Set divider MOD value.
0x600
RW
