Classic PCI Configuration Space

November 2005

SCPS097B

4.5

Class Code and Revision ID Register

This read-only register categorizes the base class, subclass, and programming interface of the bridge. The

base class is 06h, identifying the device as a bridge. The subclass is 04h, identifying the function as a

PCI-to-PCI bridge, and the programming interface is 00h. Furthermore, the TI device revision is indicated in

the lower byte (02h). See Table 4−4 for a complete description of the register contents.

PCI register offset:

08h

Read-only

Default value:

0604 0002h

BIT NUMBER

RESET STATE

BIT NUMBER

RESET STATE

Table 4−4. Class Code and Revision ID Register Description

BIT

FIELD NAME

ACCESS

DESCRIPTION

31:24

BASECLASS

Base class. This field returns 06h when read, which classifies the function as a bridge device.

23:16

SUBCLASS

Subclass. This field returns 04h when read, which classifies the function as a PCI-to-PCI bridge.

15:8

PGMIF

Programming interface. This field returns 00h when read.

7:0

CHIPREV

Silicon revision. This field returns the silicon revision of the function.

4.6

Cache Line Size Register

This read/write cache line size register is used by the bridge to determine how much data to prefetch when

handling delayed read transactions. The value in this register must be programmed to a power of 2. Any written

odd value (bit 0 = 1b) or value greater than 32 DWORDs is treated as 0 DWORDs.

PCI register offset:

0Ch

Read/Write

Default value:

00h

BIT NUMBER

RESET STATE

4.7

Primary Latency Timer Register

This read-only register has no meaningful context for a PCI Express device and returns the value 00h when

read.

PCI register offset:

0Dh

Read-only

Default value:

00h

BIT NUMBER

RESET STATE

4.8

Header Type Register

This read-only register indicates that this function has a type one PCI header. Bit 7 of this register is 0b

indicating that the bridge is a single-function device.

PCI register offset:

0Eh

Read-only

Default value:

01h

BIT NUMBER

RESET STATE
