86 / 150 page  Classic PCI Configuration Space 74 November 2005 SCPS097B 4.63 Control and Diagnostic Register 2 The contents of this register are used for monitoring status and controlling behavior of the bridge. See Table 4−37 for a complete description of the register contents. It is recommended that all values within this register be left at the default value. Improperly programming fields in this register may cause interoperability or other problems. PCI register offset: C8h Register type: Read/Write Default value: 3214 6000h BIT NUMBER 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 RESET STATE 0 0 1 1 0 0 1 0 0 0 0 1 0 1 0 0 BIT NUMBER 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 RESET STATE 0 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 Table 4−37. Control and Diagnostic Register 2 Description BIT FIELD NAME ACCESS DESCRIPTION 31:24† N_FTS_ ASYNC_CLK RW N_FTS for asynchronous clock. When bit 6 (CCC) of the link control register (offset A0h, see Section 4.53) is clear, the value in this field is the number of FTS that are sent on a transition from L0s to L0. This field shall default to 32h. 23:16† N_FTS_ COMMON_ CLK RW N_FTS for common clock. When bit 6 (CCC) of the link control register (offset A0h, see Section 4.53) is set, the value in this field is the number of FTS that are sent on a transition from L0s to L0. This field defaults to 14h. 15:13 PHY_REV R PHY revision number 12:8† LINK_NUM RW Link number 7:6 RSVD R Reserved. Returns 00b when read. 5:0† RSVD RW Reserved. Bits 5:0 default to 000000b. If this register is programmed via EEPROM or another mechanism, then the value written into this field must be 000000b. † These bits are reset by a PCI Express reset (PERST), a GRST, or the internally-generated power-on reset. 4.64 Subsystem Access Register The contents of this read/write register are aliased to the subsystem vendor ID and subsystem ID registers at PCI offsets 84h and 86h. See Table 4−38 for a complete description of the register contents. PCI register offset: D0h Register type: Read/Write Default value: 0000 0000h BIT NUMBER 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 RESET STATE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 BIT NUMBER 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 RESET STATE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Table 4−38. Subsystem Access Register Description BIT FIELD NAME ACCESS DESCRIPTION 31:16† SubsystemID RW Subsystem ID. The value written to this field is aliased to the subsystem ID register at PCI offset 86h (see Section 4.45). 15:0† SubsystemVendorID RW Subsystem vendor ID. The value written to this field is aliased to the subsystem vendor ID register at PCI offset 84h (see Section 4.44). † These bits are reset by a PCI Express reset (PERST), a GRST, or the internally-generated power-on reset. |
|
