Memory-Mapped TI Proprietary Register Space

123

November 2005

SCPS097B

Table 6−14. Serial IRQ Status Register Description (Continued)

BIT

FIELD NAME

ACCESS

DESCRIPTION

IRQ8

RCU

IRQ 8 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted

IRQ7

RCU

IRQ 7 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted

IRQ6

RCU

IRQ 6 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted

IRQ5

RCU

IRQ 5 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted

IRQ4

RCU

IRQ 4 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted

IRQ3

RCU

IRQ 3 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted

IRQ2

RCU

IRQ 2 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted

IRQ1

RCU

IRQ 1 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted

IRQ0

RCU

IRQ 0 asserted. This bit indicates that the IRQ has been asserted.

0 = Deasserted

1 = Asserted
