ADP1611
Rev. 0 | Page 9 of 20
CH1 10.0mV
Ω
M2.00
µs
A CH1
4.8mV
2
1
CH2 200mV
VIN = 5V
VOUT = 20V
COUT = 10µF
L = 10
µH
FSW = 700kHz
RC = 400kΩ
CC = 100pF
CH1 = ILOAD 200mA/DIV
CH2 = VOUT 200mV/DIV
T
571.200
µs
Figure 22. Load Transient Response, 700 kHz, VOUT = 20 V
CH1 10.0mV
Ω
M200
µs
A CH1
7.20mV
2
1
CH2 200mV
VIN = 5V
VOUT = 20V
COUT = 10µF
L = 10
µH
FSW = 1.2MHz
RC = 400kΩ
CC = 100pF
CH1 = ILOAD 200mA/DIV
CH2 = VOUT 200mV/DIV
T
488.000
µs
Figure 23. Load Transient Response, 1.2 MHz, VOUT = 20 V
CH1 10.0mV
Ω
M200
µs
A CH3
680mV
4
3
2
1
CH3 1.00V
CH2 10.0V
CH4 2.00V
VIN = 5V
VOUT = 20V
IOUT = 200mA
CSS = 0F
CH1 = IL 2A/DIV
CH2 = VOUT 10V/DIV
CH3 = SD 1V/DIV
CH4 = COMP 2V/DIV
Figure 24. Start-Up Response from Shutdown, CSS = 0 F
CH1 10.0mV
Ω
M400
µs
A CH3
680mV
4
3
2
1
CH3 1.00V
CH2 10.0V
CH4 2.00V
VIN = 5V
VOUT = 20V
IOUT = 200mA
CSS = 100nF
CH1 = IL 2A/DIV
CH2 = VOUT 10V/DIV
CH3 = SD 1V/DIV
CH4 = COMP 2V/DIV
Figure 25. Start-Up Response from Shutdown, CSS = 100 nF
