1. Electrical Specifications

Table 1. DC Operating Characteristics

VDD_A =3.3 V±5%, VDD =3.3 V±5%

Parameter

Symbol

Test Condition

Min

Max

Unit

3.3 V Core Supply Voltage

VDD/VDD_A

3.3 V ±5%

3.135

3.465

V

3.3 V I/O Supply Voltage1

VDD_IO

1.05 V to 3.3 V ±5%

0.9975

3.465

V

3.3 V Input High Voltage

VIH

VDD

2.0

VDD+0.3

V

3.3 V Input Low Voltage

VIL

VSS-0.3

0.8

V

Input Leakage Current2

IIL

0 < VIN < VDD

–5

+5

µA

3.3 V Input High Voltage3

VIH_FS

VDD

0.7

VDD+0.3

V

3.3 V Input Low Voltage3

VIL_FS

VSS–0.3

0.35

V

3.3 V Input Low Voltage

VIL_Tri

0

0.8

V

3.3 V Input Med Voltage

VIM_Tri

1.2

1.8

V

3.3 V Input High Voltage

VIH_Tri

2.2

VDD

V

3.3 V Output High Voltage4

VOH

IOH =–1mA

2.4

—

V

3.3 V Output Low Voltage4

VOL

IOL =1mA

—

0.4

V

Input Capacitance5

CIN

2.5

4.5

pF

Output Capacitance5

COUT

2.5

4.5

pF

Pin Inductance

LPIN

—7

nH

Ambient Temperature

TA

No Airflow

–40

85

°C

Notes:

1. VDD_IO applies to the low-power NMOS push-pull HCSL compatible outputs.

2. Input Leakage Current does not include inputs with pull-up or pull-down resistors. Inputs with resistors should state

current requirements.

3. Internal voltage reference is to be used to guarantee VIH_FS and VIL_FS thresholds levels over full operating range.

4. Signal edge is required to be monotonic when transitioning through this region.

5. Ccomp capacitance based on pad metallization and silicon device capacitance. Not including pin capacitance.

Table 2. Current Consumption

TA = –40 to 85 °C; supply voltage VDD =3.3 V ±5%

Parameter

Symbol

Test Condition

Min

Typ

Max

Unit

Operating Current

IDDVDD

133 MHz, VDD Rail

—

18

25

mA

IDDVDDA

133 MHz, VDDA + VDDR, PLL Mode

—

17

20

mA

IDDVDDIO

133 MHz, CL = Full Load, VDD IO Rail

—

85

110

mA

Power Down Current IDDVDDPD

Power Down, VDD Rail

—

0.4

1

mA

IDDVDDAPD

Power Down, VDDA Rail

—

2

5

mA

IDDVDDIOPD

Power Down, VDD_IO Rail

—

0.2

0.5

mA
