Table 4. Phase Jitter

Parameter

Test Condition

Min

Typ

Max

Unit

Phase Jitter

PLL Mode

PCIe Gen 1, Common Clock1,2,3

—29

86

ps

PCIe Gen2 Low Band, Common Clock

F < 1.5 MHz1,3,4,5

—

2.0

3.0

ps

(RMS)

PCIe Gen2 High Band, Common Clock

1.5 MHz < F < Nyquist1,3,4,5

—

1.9

3.1

ps

(RMS)

PCIe Gen 3, Common Clock

(PLL BW 2–4 MHz, CDR = 10 MHz)1,3,4,5

—0.45

1.0

ps

(RMS)

PCIe Gen 3 Separate Reference No Spread, SRNS

(PLL BW of 2–4 or 2–5 MHz, CDR = 10 MHz)1,3,4,5

—

0.32

0.71

ps

(RMS)

PCIe Gen 4, Common Clock

(PLL BW of 2–4 or 2–5 MHz, CDR = 10 MHz)1,4,5,8

—0.45

1.0

ps

(RMS)

Intel® QPI & Intel SMI

(4.8 Gbps or 6.4 Gb/s, 100 or 133 MHz, 12 UI)1,6,7

—0.21

0.5

ps

(RMS)

Intel QPI & Intel SMI

(8 Gb/s, 100 MHz, 12 UI)1,6

—0.13

0.3

ps

(RMS)

Intel QPI & Intel SMI

(9.6 Gb/s, 100 MHz, 12 UI)1,6

—0.11

0.2

ps

(RMS)

Notes:

1. Post processed evaluation through Intel supplied Matlab* scripts. Defined for a BER of 1E-12. Measured values at a

smaller sample size have to be extrapolated to this BER target.

2.

ζ = 0.54 implies a jitter peaking of 3 dB.

3. PCIe* Gen3 filter characteristics are subject to final ratification by PCISIG. Check the PCI-SIG for the latest

specification.

4. Measured on 100 MHz PCIe output using the template file in the Intel-supplied Clock Jitter Tool V1.6.3.

5. Measured on 100 MHz output using the template file in the Intel-supplied Clock Jitter Tool V1.6.3.

6. Measured on 100 MHz, 133 MHz output using the template file in the Intel-supplied Clock Jitter Tool V1.6.3.

7. These jitter numbers are defined for a BER of 1E-12. Measured numbers at a smaller sample size have to be

extrapolated to this BER target.

8. Gen 4 specifications based on the PCI-Express Base Specification 4.0 rev. 0.5.

9. Download the Skyworks Solutions PCIe Clock Jitter Tool at https://www.skyworksinc.com/en/application-pages/pci-

express-learning-center.
