Si53112

Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com

21

Rev. 1.1 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • September 2, 2021

Table 18. Byte 1: Output Enable Control Register

Bit

Description

If Bit = 0

If Bit = 1

Type

Default

Output(s)

Affected

0

Output Enable DIF 0

Low/Low for

Si53112

Enabled

RW

1

DIF[0]

1

Output Enable DIF 1

Low/Low for

Si53112

Enabled

RW

1

DIF[1]

2

Output Enable DIF 2

Low/Low for

Si53112

Enabled

RW

1

DIF[2]

3

Output Enable DIF 3

Low/Low for

Si53112

Enabled

RW

1

DIF[3]

4

Output Enable DIF 4

Low/Low for

Si53112

Enabled

RW

1

DIF[4]

5

Output Enable DIF 5

Low/Low for

Si53112

Enabled

RW

1

DIF[5]

6

Output Enable DIF 6

Low/Low for

Si53112

Enabled

RW

1

DIF[6]

7

Output Enable DIF 7

Low/Low for

Si53112

Enabled

RW

1

DIF[7]
