1 / 64 page

1

Sensing distance

Supply voltage

Output

100 mA

12 to 24 VDC

(Optical fiber series)

Optical Fiber Photoelectric Sensor

E3X

Leading-edge Features and

Long-distance Sensing in an Optical

Fiber Photoelectric Sensor

E3X-T

jj with Auto-tuning Function

Automatic Sensitivity Adjustment

E3X-H11 High-sensitivity Model

Senses Distances Twice as Far as those of

E3X-A

jj and Performs Detailed Sensing

Operations Using the Variable Hysteresis

Function

E3X-A

jj Standard Model

A High-speed Response of 200

µs

E3X-F

jj High-speed Model

Pulse Lighting Mechanism Enables a

High-speed Response of 20

µs

E3X-VG

jj Mark Sensor Model

Green Light Source Accurately Senses Subtle

Differences in Color at a Speed of 200

ms

Ordering Information

Model Number Legend:

E3X -

1

234

1. Classification

T: Auto-tuning

H: High-sensitivity

A: General-purpose

F: Shorter response time

V: For mark sensor

2. Light Source

None: Red (standard)

G:

Green

3. Outputs

1: NPN (without self-diagnosis)

2: NPN (with self-diagnosis)

4: PNP (without self-diagnosis)

5: PNP (with self-diagnosis)

4. Output Form

1: Cable

Accessories (Order Separately)

(Cannot be used with the E3X-T

jj.)
