30 / 64 page  E3X E3X 30 Number of Turns of Sensitivity Adjuster and Sensing Distance (Typical) E3X-H/E32-D11L Color Sensing (Typical) Green Light Source E3X-VG j /E32-D11L Sensitivity adjuster Color paper (2.5 x 2.5 cm) Munsell chroma (MC) Number of turns E3X-A j E3X-F j 10 ° 5 mm White CM484 Yellow CM124 Amber CM 78 Yellow green CM157 Orange CM 85 Aqua CM263 Red CM 6 Purple CM379 Magenta CM431 Blue CM336 Green CM241 Black CM489 Sensing Object: White Paper of 5 x 5 cm The following graph shows the relationship between colors and the number of turns of the sensitivity adjustor when the E32-D11L is in operation with the sensing distance adjusted to 5 mm. E3X-A, -F/E32-D11L Sensing Object: White Paper of 10 x 10 cm with E3X-A and 5 x 5 cm with E3X-F Sensitivity adjuster |
|
