IS25LE01G
IS25WE01G
Integrated Silicon Solution, Inc.- www.issi.com
45
Rev. A6
01/14/2025
Table 7.4 PPB/DYB and Sector/Block mapping when Block Size is 256KB (TBPARM bit is Reserved)
Memory
Density
PPB Group
DYB Group
Block No.
(256Kbyte)
Sector No.
Sector Size
(Kbyte)
Address Range
1Gb
PPB 0
DYB 0
Block 0
Sector 0
4
000 0000h
– 000 0FFFh
:
:
:
:
:
:
Sector 15
4
000 F000h
– 000 FFFFh
Sector 16
4
001 0000h
– 001 0FFFh
:
:
:
:
:
:
Sector 31
4
001 F000h
– 001 FFFFh
Sector 32
4
002 0000h
– 002 0FFFh
:
:
:
:
:
:
Sector 47
4
002 F000h
– 002 FFFFh
Sector 48
4
003 0000h
– 003 0FFFh
:
:
:
:
:
:
Sector 63
4
03 F000h
– 03 FFFFh
:
:
:
:
:
:
PPB 127
DYB 127
Block 127
Sector 8128
4
1FC0000h
– 1F C0FFFh
:
:
:
:
:
:
Sector 8143
4
1FC F000h
– 1FC FFFFh
:
:
:
Sector 8176
4
1FF 0000h
– 1FF 0FFFh
:
:
:
:
:
:
Sector 8191
4
1FF F000h
– 1FF FFFFh
:
:
:
:
:
:
PPB 511
DYB 511
Block 511
Sector 32704
4
7FC 0000h
– 7FC 0FFFh
:
:
:
:
:
:
Sector 32719
4
7FC F000h
– 7FC FFFFh
Sector 32720
4
7FD 0000h
– 7FD 0FFFh
:
:
:
:
:
:
Sector 32735
4
7FD F000h
– 7FD FFFFh
Sector 32736
4
7FE 0000h
– 7FE 0FFFh
:
:
:
:
:
:
Sector 32751
4
7FE F000h
– 7FE FFFFh
Sector 32752
4
7FF 0000h
– 7FF 0FFFh
:
:
:
:
:
:
Sector 32767
4
7FF F000h
– 7FF FFFFh
