R3111x
23
 R3111E (TO-92) is the discontinued product as of April, 2017.
 Package Dimensions (SC-88A)
2.0±0.2
1.3±0.2
5
1
2
3
4
Unit : mm
0.2
A
0.65
0.15±0.07
0～14
0.15
+
0.1
-
0.05
B
0.10 S AB
0.10 S
S
 Mark Specification (SC-88A)
 : Product Code …Refer to Mark Specification Table (SC-88A).

: Lot No. ………... Alphanumeric Serial Number
①②③
④⑤⑥
5
1
2
3
4
