5 / 43 page

R3111x

 R3111E (TO-92) is the discontinued product as of April, 2017.

ABSOLUTE MAXIMUM RATINGS

Symbol

Item

Rating

Unit

VDD

Supply Voltage

VOUT

Output Voltage (CMOS)

VSS

0.3 to VDD0.3

Output Voltage (Nch)

VSS

0.3 to 12

IOUT

Output Current

Power Dissipation (TO-92)*

300

Power Dissipation (SOT-89)*

900

Power Dissipation (SOT-23-3)*

420

Power Dissipation (SOT-23-5)*

420

Power Dissipation (SC-82AB)*

380

Power Dissipation (SC-88A)*

380

Power Dissipation (SON1612-6)*

500

Operating Temperature Range

40 to 85

C

Tstg

Storage Temperature Range

55 to 125

C

* ) For Power Dissipation, please refer to PACKAGE INFORMATION.

ABSOLUTE MAXIMUM RATINGS

Electronic and mechanical stress momentarily exceeded absolute maximum ratings may cause the

permanent damages and may degrade the life time and safety for both device and system using the device

in the field. The functional operation at or over these absolute maximum ratings is not assured.

RECOMMENDED OPERATING CONDITIONS (ELECTRICAL CHARACTERISTICS)

All of electronic equipment should be designed that the mounted semiconductor devices operate within the

recommended operating conditions. The semiconductor devices cannot operate normally over the

recommended operating conditions, even if when they are used over such conditions by momentary

electronic noise or surge. And the semiconductor devices may receive serious damage when they continue

to operate over the recommended operating conditions.
