ST10C167

38/65

XX - ELECTRICAL CHARACTERISTICS

XX.1 - Absolute maximum ratings

Note

Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage

to the device. This is a stress rating only and functional operation of the device at these or any

other conditions above those indicated in the operational sections of this specification is not

implied. Exposure to absolute maximum rating conditions for extended periods may affect device

reliability. During overload conditions (V

IN>VDD or VIN<VSS) the voltage on pins with respect to

ground (V

SS) must not exceed the values defined by the Absolute Maximum Ratings.

XX.2 - Parameter interpretation

The parameters listed in the following tables

represent the characteristics of the ST10C167

and its demands on the system. Where the

ST10C167 logic provides signals with their

respective timing characteristics, the symbol “CC”

for Controller Characteristics is included in the

“Symbol” column.

Where the external system must provide signals

with their respective timing characteristics to the

ST10C167,

the

symbol

“SR”

for

System

Requirement is included in the “Symbol” column.

Symbol

Parameter

Value

Unit

VSS

Voltage on VDD pins with respect to ground

-0.5, +6.5

VSS

Voltage on any pin with respect to ground

-0.3 to VDD +0.3

Input current on any pin during overload condition

-10, +10

Absolute sum of all input currents during overload condition

|100|

Ptot

Power Dissipation

1.5

Tamb

Ambient Temperature under bias

-40, +125

°C

Tstg

Storage Temperature

-65, +150

°C
