ST10C167
55/65
XX - ELECTRICAL CHARACTERISTICS (continued)
Figure 19 : External Memory Cycle: demultiplexed bus, with/without read/write delay, extended ALE
Address
t
5
t
16
t
39
t
41
t
14
t
24
t
6
t
38
t
20
t26
t
17
t
15
t
12
t
13
t
12
t
13
t
22
Data In
t
18
t
21
t
6
t
17
t
28
t
28
Data Out
t
80
t
81
t
80
t
81
Read Cycle
Write Cycle
CLKOUT
ALE
CSx
A23-A16
(A15-A8)
Data Bus
RD
Data Bus
WR
WRL
BHE
WRH
(P0)
(P0)
