M24LR64E-R

Response format

Doc ID 022712 Rev 3

71/140

20.2

Response error code

If the Error_flag is set by the M24LR64E-R in the response, the Error code field is present

and provides information about the error that occurred.

Error codes not specified in Table 32 are reserved for future use.

Table 32.

Response error code definition

Error code

Meaning

03h

The option is not supported.

0Fh

Error with no information given.

10h

The specified block is not available.

11h

The specified block is already locked and thus cannot be locked again.

12h

The specified block is locked and its contents cannot be changed.

13h

The specified block was not successfully programmed.

14h

The specified block was not successfully locked.

15h

The specified block is read-protected.
