Command codes
M24LR64E-R
92/140
Doc ID 022712 Rev 3
Request parameter:
●
Request flags
●
UID (optional)
●
AFI
Response parameter:
●
No parameter
Response parameter:
●
Error code as Error_flag is set
–
12h: the specified block is locked and its contents cannot be changed
–
13h: the specified block was not successfully programmed
Table 57.
Write AFI request format
Request
SOF
Request
_flags
Write
AFI
UID(1)
1.
Gray color means that the field is optional.
AFI
CRC16
Request
EOF
8 bits
27h
64 bits
8 bits
16 bits
Table 58.
Write AFI response format when Error_flag is NOT set
Response
SOF
Response_flags
CRC16
Response
EOF
8 bits
16 bits
Table 59.
Write AFI response format when Error_flag is set
Response
SOF
Response_
flags
Error code
CRC16
Response
EOF
8 bits
8 bits
16 bits
Figure 61.
Write AFI frame exchange between VCD and M24LR64E-R
VCD
SOF
Write AFI
request
EOF
M24LR64E-R
<-t1-> SOF
Write AFI
response
EOF
Write sequence
when error
M24LR64E-R
<------------------ Wt --------------> SOF
Write AFI
response
EOF
