background image
Command codes
M24LR64E-R
90/140
Doc ID 022712 Rev 3
Response parameter:
●
No parameter
Response parameter:
●
Error code as Error_flag is set:
–
03h: the option is not supported
When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that
starts the Select command to the end of the M24LR64E-R response.
When configured in the RF write in progress mode, the RF WIP/BUSY pin remains in high-Z
state.
26.7
Reset to Ready
On receiving a Reset to Ready command, the M24LR64E-R returns to the Ready state if no
error occurs. In the Addressed mode, the M24LR64E-R answers an error code only if the
UID is equal to its own UID. If not, no response is generated.
Table 52.
Select Block response format when Error_flag is NOT set
Response
SOF
Response_flags
CRC16
Response
EOF
8 bits
16 bits
Table 53.
Select response format when Error_flag is set
Response
SOF
Response_
flags
Error code
CRC16
Response
EOF
8 bits
8 bits
16 bits
Figure 59.
Select frame exchange between VCD and M24LR64E-R
VCD
SOF
Select
request
EOF
M24LR64E-R
<-t1-> SOF
Select
response
EOF
Table 54.
Reset to Ready request format
Request
SOF
Request_
flags
Reset to
Ready
UID(1)
1.
Gray color means that the field is optional.
CRC16
Request
EOF
8 bits
26h
64 bits
16 bits
