4.9 How to Program a Post Processing

4.9.1 2 registers for the mode:

PDEC (0x62) to define the type of PostProcessing

4.9.2 1 or 2 registers to control the “PostProcessing”

Prologic decoder (PDEC = 0x01):

Remark: When playing “Dolby Digital Prologic encoded”, if PL_DOWNMIX is correctly set, Prologic decoder’ is

automatically applied even if the register “PDEC” different to 1.

CDDA frames

Beep Tone Generator

MP3 frame elementary streams

IEC61937 Input with Dolby Digital frames

IEC61937 Input with MPEG1 frames

IEC61937 Input with MPEG2 frames

MPEG2 PES carrying Linear PCM for DVD Audio

MPEG2 PES carrying MPL for DVD Audio

PDEC

MODE

0x01

Prologic

0x02

MPEG 1/2 Dynamic Range

0x08

Double Stereo

0x10

DC Remove

0x20

Deemphasis filter

PL ABL WS (0x64)

Effect

AutoBalance

WideSurround

PL DOWNMIX (0x65)

Prologic DownMix

0,1,2

Prologic not applied

3/0 (L, R, C)

2/1 (L, R, Ls) Phantom

3/1 (L, R, Ls)

2/2 (L, R, Ls, Rs) Phantom

3/2 (L, C, R, Ls, Rs)

STREAMSEL

DECODESEL

MODE
