background image
STA310
46/90
Delay on left channel, expressed in number of group
of 16 samples. LDLY = delay (ms) * Fs (kHz) / 16
RDLY
Right channel delay
Address: 0x58
Type: R/W
Software Reset: NC
Hardware Reset:UND
Delay on right channel, expressed in number of
group of 16 samples. RDLY = delay (ms)*Fs (kHz)/16
CDLY
Centre channel delay
Address: 0x59
Type: R/W
Software Reset: NC
Hardware Reset: UND
Description:
Delay on center channel, expressed in number of
group of 16 samples. CDLY = delay (ms) * Fs (kHz) /
16
SUBDLY
Subwoofer channel delay
Address: 0x5A
Type: R/W
Software Reset: NC
Hardware Reset: UND
Description:
Delay on subwoofer channel, expressed in number of
group of 16 samples. SUBDLY = delay (ms) * Fs
(kHz) / 16
LSDLY
Left surround channel delay
Address: 0x5B
Type: R/W
Software Reset: NC
Hardware Reset: UND
Delay on left surround channel, expressed in number
of group of 16 samples. LSDLY = delay (ms) * Fs
(kHz) / 16
RSDLY
Right surround channel delay
Address: 0x5C
Type: R/W
Software Reset: NC
Hardware Reset: UND
Description:
Delay on right surround channel, expressed in num-
ber of group of 16 samples. RSDLY = delay (ms) * Fs
(kHz) / 16.
When only one surround channel is used, this regis-
ter must be reset at initialization.
LVDLY
Left VCR channel delay
Address: 0xAF
Type: R/W
Software Reset: NC
Hardware Reset: UND
Description:
Delay on left VCR channel, expressed in number of
group of 16 samples.
LSDLY = delay (ms) * Fs (kHz) / 16
76
54
321
0
76
54
321
0
76
54
321
0
76
54
321
0
76
54
321
0
76
54
321
0
