H7CC-A

Counter

Note: 1. When the present value reaches 999999, it returns to 0.

2. Counting cannot be performed during reset/reset 1 input.

3. If reset/reset 1 is input while one-shot output is ON, one-shot output turns OFF.

4. If there is power interruption while output is ON, output will turn ON again when the power supply has recovered, if memory backup is

enabled.

For one-shot output, output will turn ON again for the duration of the output time setting once the power supply has recovered.

5. Do not use the counter function in applications where the count may be completed (again) while one-shot output is ON.

6. The setting range is 0 to 999999.

Input mode

Operation after count

completion

Output

mode

setting

DOWN

The present value

continues to increase/

decrease for the one-shot

output time, but returns to

the reset start status after

the one-shot output time

has elapsed.

The outputs repeat one-

shot operation.

OUT1 self-holding output

turns OFF after the OUT2

one-shot output time.

The OUT1 one-shot output

time is independent of

OUT2.

UP/DOWN A, B, C

UP/DOWN D, E, F

DOWN

The present value display

and OUT1 self-holding

output is held until reset/

reset 1 is input.

OUT1 and OUT2 are

independent.

UP/DOWN A, B, C

UP/DOWN D, E, F

Self-holding

output

Self-holding

output

One-shot output from OUT1

One-shot

output from OUT2

(The one-shot output time

can be set in the range

0.01 to 99.99s.)

Reset/

reset 1

OUT1

OUT2

999999

Set value 2

Set value 1

Reset/

reset 1

OUT1

OUT2

999999

Set value 2

Set value 1

Reset/

reset 1

OUT1

OUT2

999999

Set value 2

Set value 1

Reset/

reset 1

OUT1

OUT2

999999

Set value 2

Set value 1

Reset/

reset 1

OUT1

OUT2

999999

Set value 2

Set value 1

Reset/

reset 1

OUT1

OUT2

999999

Set value 2

Set value 1

Reset/

reset 1

OUT1

OUT2

999999

Set value 2

Set value 1

Reset/

reset 1

OUT1

OUT2

999999

Set value 2

Set value 1
