H7CC-R

Dimensions

(Unit: mm)

Tachometers

63.7

14.4

× 48

44.8

× 44.8

Dimensions without Flush Mounting Adapter

H7CC-R

Note: 1. The mounting panel thickness should be 1

to 5 mm.

2. To allow easier operation, it is

recommended that Adapters be mounted so

that the gap between sides with hooks is at

least 15 mm (i.e., with the panel cutouts

separated by at least 60 mm).

3. It is possible to horizontally mount Timers

side by side. Attach the Flush Mounting

Adapters so that the surfaces without hooks

are on the sides of the Timers. If Counters/

Tachometers are mounted side by side,

however, water resistance will be lost.

60 min.

15 min.

+0.6

−0

+0.6

−0

n side by side mounting

With Y92A-48F1 attached.

With Y92A-48 attached.

A=(48n

−2.5)

−0

A=(51n

−5.5) +1

−0

A={48n

−2.5+(n−1)×4} +1

−0

Panel Cutouts

Panel cutouts are as shown below

(according to DIN43700).

(51)

7.5

89.9

Dimensions with Flush Mounting Adapter

(Adapter and Waterproof Packing Ordered Separately)

H7CC-R

Dimensions with Front Connecting Socket

H7CC-R

P2CF-11(-E) (order separately)

Front Connecting Socket

100.9

103.2

* These dimensions vary with the kind of DIN track

(reference value).
