H7CC-R

Operating Procedures

Parameters can be set with the operation keys on the front panel.

Refer to the following for the detailed procedure.

Step1

(AMD compatible)

amd

The H7CC-R

@ is a Counter that contains more than one functional counter.

When using the Counter in any mode other than the default mode, use the following chart to enter

Configuration Selection Mode and set the functions that are suitable to the application. (Default mode: Tachometer)

(Tachometer)

Select the function using the UP1 Key (DW1 Key). (H7CC-R11

@ only)

taco

func

UP1+UP6

DW1+DW6

(Press and hold for 2 s)

Run mode

Power ON

Configuration

selection mode

• Set the decimal point position using the UP1 Key (DW1 Key).

Decimal point

position

(DP)

(No decimal point) (One digit after

decimal point)

(Two digits after

decimal point)

(Three digits after

decimal point)

10khz

cnts

*1. In the case of the -R11W@ type,

set the tachometer output mode 1 or 2

with the UP or DOWN Key.

UP1+UP3 or DW1+DW3

(Press and hold for 2 s)

UP1+UP3 or DW1+DW3

(Press and hold for 2 s)

Run mode

Power ON

Function

setting mode

* Use UP1+UP3 to move up and

DW1+DW3 to move down

(10 ms)

(1 ms)

Step2

(99.999)

(1.000)

(0.001)

From

Prescale value

(PSCL)

Parameters are set with the operation keys on the front panel.

Change to Function Setting Mode.

(LO)

(HI)

(LO)

(HI)

(30 Hz)

(10 kHz)

The characters displayed in reverse video are the default settings.

In the function setting mode, the status indicator of the keys that can be set lights up.

(Example) In the case of the prescale value (PSCL)

A value from 0.001 to 99.999 can be set, and therefore, the status indicator

of the UP1 Key to UP5 Key (DW1 Key to DW5 Key) lights up.

hilo

30hz

area

hihi

10ms

1ms

lolo

0.001

99.999

1.000

(AREA)

(HI-HI)

(LO-LO)

(HI-LO)

In the case of AMD compatibility

*1 If the mode is switched to the function setting mode during operation, operation will continue.

*2 Changes made to settings in function setting mode are enabled for the first time when the

mode is changed to run mode. Also, when settings are changed, the counter is reset

(present value initialized and output turned OFF) on returning to run mode.

Tachometer

output

mode 1

(TO1M)

Tachometer

output

mode 2

(TO2M)

Tachometer

output mode

(TOTM)

• Set the tachometer output mode using the UP1 Key (DW1 Key).

Counting

speed

(CNTS)

• Set the counting speed using the UP1 Key (DW1 Key).

Note: The indicator display is disabled during the upper or lower

limit setting.

1000

pscl

For details on operations in run mode, refer to page 55.
