P9221-R3 Datasheet
© 2017 Integrated Device Technology, Inc.
25
October 20, 2017
Figure 25. State Diagram for User Data Transmission from the P9221-R3 to the P9242-R3
Is the P9221-R3 in
the power transfer phase
(register 014AHEX = 05HEX)?
Load outgoing user data registers
(registers 0089HEX to 0090HEX) and
set the data header register
(0089HEX) accordingly
Is the communication
channel free (bit 0 of
register 004EHEX = “0”)?
Yes
Yes
Set bit 0 of register 004EHEX to “1”
to trigger the communication
The P9221-R3 will reset bit 0 of
register 004EHEX to “0” after sending
the data into the channel
