Section 6 Bus Controller (BSC)

Rev.1.00 Jun. 07, 2006 Page 223 of 1102

REJ09B0294-0100

6.9.7

Wait Control

In the data cycle of the address/data multiplexed I/O interface, program wait insertion and pin wait

insertion by the

WAIT pin are enabled in the same way as in the basic bus interface. For details,

refer to section 6.6.4, Wait Control.

Wait control settings do not affect the address cycles.

6.9.8

Read Strobe (

RD) Timing

In the address/data multiplexed I/O interface, the read strobe timing of data cycles can be modified

in the same way as in basic bus interface. For details, refer to section 6.6.5, Read Strobe (

RD)

Timing.

Figure 6.34 shows an example when the read strobe timing is modified.
