ADRF6806
Data Sheet
Rev. B | Page 34 of 36
AGILENT E3631A
POWER SUPPLY
REF
RF SWITCH MATRIX
ADRF6806
EVALUATION BOARD
RF
6dB
3dB
6dB
I CH
10-PIN
CONNECTION
(+5V VPOS1,
+3.3V VPOS2,
DC MEASURE)
9-PIN D-SUB CONNECTION
(VCO AND PLL PROGRAMMING)
IE
IEEE
AGILENT DMM
(FOR I 3.3V VP2 MEAS.)
Q CH
AGILENT DMM
(FOR I-5V VP1 MEAS.)
REF
E IEEE
IEEE
IEEE
IEEE
IEEE
IEEE
6dB
RF1
AGILENT N8974A
NOISE FIGURE ANALYZER
AGILENT 346B
NOISESOURCE
AGILENT 8665B
LOW NOISE SYN
SIGNAL GENERATOR
10MHz
LOW-PASS FILTER
RF
3dB
AGILENT 34980A
MULTIFUNCTION
SWITCH
(WITH 34950 AND 2×
34921 MODULES)
Figure 51. Noise Figure Characterization Setup
