background image
65
Rev 1.3
Address: 0x4000BC1C Reset: 0x0
Register 7.8. GPIO_WAKEFILT: GPIO Wakeup Filtering Register
Bit
31
30
29
28
27
26
25
24
Name
0
0
0
0
0
0
0
0
Bit
23
22
21
20
19
18
17
16
Name
0
0
0
0
0
0
0
0
Bit
15
14
13
12
11
10
9
8
Name
0
0
0
0
0
0
0
0
Bit
7
6
5
4
3
2
1
0
Name
0
0
0
0
IRQD_WAKE_
FILTER
SC2_WAKE_
FILTER
SC1_WAKE_
FILTER
GPIO_WAKE_
FILTER
Bitname
Bitfield
Access
Description
IRQD_WAKE_FILTER
[3]
RW
Enable filter on GPIO wakeup source IRQD.
SC2_WAKE_FILTER
[2]
RW
Enable filter on GPIO wakeup source SC2 (PA2).
SC1_WAKE_FILTER
[1]
RW
Enable filter on GPIO wakeup source SC1 (PB2).
GPIO_WAKE_FILTER
[0]
RW
Enable filter on GPIO wakeup sources enabled by the GPIO_PnWAKE regis-
ters.
