MB9BF412RPMC-G-JNE2 데이터시트(PDF) 42 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB9BF412RPMC-G-JNE2 데이터시트(HTML) 42 Page - Cypress Semiconductor |
|
|
42 / 112 page  Document Number: 002-05615 Rev. *D Page 42 of 112 MB9B410R Series Type Circuit Remarks E − CMOS level output − CMOS level hysteresis input − With pull-up resistor control − With standby mode control − Pull-up resistor: Approximately 50 kΩ − IOH = -4 mA, IOL = 4 mA − When this pin is used as an I2C pin, the digital output − P-ch transistor is always off − +B input is available F − CMOS level output − CMOS level hysteresis input − With input control − Analog input − With pull-up resistor control − With standby mode control − Pull-up resistor: Approximately 50 kΩ − IOH = -4 mA, IOL = 4 mA − When this pin is used as an I2C pin, the digital output − P-ch transistor is always off − +B input is available P-ch P-ch N-ch R P-ch P-ch N-ch R Digital output Digital output Pull-up resistor control Digital input Standby mode Control Digital output Digital output Pull-up resistor control Digital input Standby mode Control Analog input Input control |
|
