77 / 112 page  Document Number: 002-05615 Rev. *D Page 77 of 112 MB9B410R Series NAND Flash Mode (VCC = 2.7V to 5.5V, VSS = 0V, TA = -40°C to +85°C) Parameter Symbol Pin name Conditions Value Unit Min Max MNREX Min pulse width tNREW MNREX VCC ≥ 4.5 V MCLK×n-3 - ns VCC < 4.5 V Data setup → MNREX ↑ time tDS – NRE MNREX MADATA[15:0] VCC ≥ 4.5 V 20 - ns VCC < 4.5 V 38 - MNREX ↑ → Data hold time tDH – NRE MNREX MADATA[15:0] VCC ≥ 4.5 V 0 - ns VCC < 4.5 V MNALE ↑ → MNWEX delay time tALEH - NWEL MNALE MNWEX VCC ≥ 4.5 V MCLK×m-9 MCLK×m+9 ns VCC < 4.5 V MCLK×m-12 MCLK×m+12 MNALE ↓ → MNWEX delay time tALEL - NWEL MNALE MNWEX VCC ≥ 4.5 V MCLK×m-9 MCLK×m+9 ns VCC < 4.5 V MCLK×m-12 MCLK×m+12 MNCLE ↑ → MNWEX delay time tCLEH - NWEL MNCLE MNWEX VCC ≥ 4.5 V MCLK×m-9 MCLK×m+9 ns VCC < 4.5 V MCLK×m-12 MCLK×m+12 MNWEX ↑ → MNCLE delay time tNWEH - CLEL MNCLE MNWEX VCC ≥ 4.5 V 0 MCLK×m+9 ns VCC < 4.5 V MCLK×m+12 MNWEX Min pulse width tNWEW MNWEX VCC ≥ 4.5 V MCLK×n-3 - ns VCC < 4.5 V MNWEX ↓ → Data delay time tNWEL – DV MNWEX MADATA[15:0] VCC ≥ 4.5 V - 9 + 9 ns VCC < 4.5 V - 12 +12 MNWEX ↑ → Data hold time tNWEH – DX MNWEX MADATA[15:0] VCC ≥ 4.5 V 0 MCLK×m+9 ns VCC < 4.5 V MCLK×m+12 Note: − When the external load capacitance = 30 pF. (m=0 to 15, n=1 to 16) NAND Flash Read MCL K MNREX MADATA[15:0] Read |
|
