background image
Document Number: 002-05615 Rev. *D
Page
89 of 112
MB9B410R Series
12.4.11
External Input Timing
(VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C)
Parameter
Symbol
Pin name
Conditions
Value
Unit
Remarks
Min
Max
Input pulse width
tINH,
tINL
ADTG
-
2tCYCP*
-
ns
A/D converter
trigger input
FRCKx
Free-run timer input
clock
ICxx
Input capture
DTTIxX
-
2tCYCP*
-
ns
Wave form
generator
INTxx,
NMIX
Except
Timer mode,
Stop mode
2tCYCP + 100*
-
ns
External interrupt
NMI
Timer mode,
Stop mode
500*2
-
ns
*: tCYCP indicates the APB bus clock cycle time.
About the APB bus number which A/D converter, Multi-function Timer, External interrupt is connected to, see 8 Block Diagram in
this data sheet.
