21 / 87 page ![]() CMV2000 Functional description Datasheet • PUBLIC • Document Feedback DS000734 • v8-00 • 2025-Jul-07 21 / 87 / 7 Functional description 7.1 Sensor architecture Figure 2 shows the image sensor architecture. The internal sequencer generates the necessary signals for image acquisition. The image is stored in the pixel (global shutter) and is then read out sequentially, row-by-row. On the pixel output, an analog gain of x1, x1.2, x1.4 and x1.6 is possible. The pixel values then passes to a column ADC cell, in which ADC conversion is performed. The digital signals are then read out over multiple LVDS channels. Each LVDS channel reads out 128 adjacent columns of the array. In the Y-direction, rows of interest are selected through a row-decoder which allows a flexible windowing. Control registers are foreseen for the programming of the sensor. These register parameters are uploaded via a four-wire SPI interface. A temperature sensor which can be read out over the SPI interface is also included. 7.1.1 Pixel array The pixel array consists of 2048 x 1088 square global shutter pixels with a pitch of 5.5 µm (5.5 μm x 5.5 μm). This results in an optical area of close to 2/3 optical inch (12.7 mm). This means that most off-the-shelf C-mount lenses can be used. The pixels are designed to achieve maximum sensitivity with low noise and low PLS specifications. Micro lenses are placed on top of the pixels for improved fill factor and quantum efficiency (>50%). 7.1.2 Analog front end The analog front end consists of 2 major parts, a column amplifier block and a column ADC block. The column amplifier prepares the pixel signal for the column ADC and applies analog gain if desired (programmable using the SPI interface). The column ADC converts the analog pixel value to a 10 or 12-bit value. A digital offset can also be applied to the output of the column ADC’s. All gain and offset settings can be programmed using the SPI interface. |
|
