background image
STLS2F01
Interface description
11/48
2.4
Local bus signals
The local bus provides a simple bus interface for system boot ROM and I/O device. The
interface is designed for chip-connect simplicity.
The local bus signals are listed in Table 4.
Table 4.
Local bus signals
Name
Input/output
Description
LIO_AD[15:0]
I/O
Local I/O address and data bus
When ADLOCK valid output the most significant 16 bits
LIO_A[7:0]
O
Lowest significant 8-bit address bus
LIO_CSn
O
Local I/O chip select
LIO_ROMCSn
O
Local I/O ROM chip select
LIO_WRn
O
Local I/O write enable
LIO_RDn
O
Local I/O read enable
LIO_ADLOCK
O
Local I/O address lock
LIO_DIR
O
Local I/O direction
LIO_DEN
O
Local I/O device enable
