background image
STLS2F01
Electrical characteristics
37/48
6
Electrical characteristics
6.1
Absolute maximum rating
Stresses above the absolute maximum ratings listed in Table 13 may cause permanent
damage to the device. These are stress ratings only and functional operation of the device
at these conditions is not implied. Exposure to maximum rating conditions for extended
period may affect device reliability.
6.2
Recommended operation environment
Table 13.
Absolute maximum rating.
Parameter
Description
Min
Max
Unit
vdd
CPU core voltage
1.2
1.3
V
vdde1v8
DDR2 voltage
1.7
1.9
V
vdde3v3
IO voltage
3.0
3.6
V
DDR2_VREF
DDR2 voltage reference
0.83
0.97
V
pll_vdd_1
1.0V PLL1 digital voltage
0.9
1.3
V
pll_vdd_0
1.0V PLL0 digital voltage
0.9
1.3
V
pllio_vdde1v8
1.8V PLL IO voltage
1.7
1.9
V
pll_vdde1v8_1
1.8V PLL1 analog voltage
1.7
1.9
V
Pll_vdde1v8_0
1.8V PLL0 analog voltage
1.7
1.9
V
pllio_vdd
1.2V PLL IO voltage
0.9
1.3
V
TS
Storage Temperature
°C
Table 14.
Recommended operating temperature, voltage supply and frequency
Parameter
Description
Min
Typ
Max
Unit
TA
Operating Temperature
0
85
°C
vdd
CPU core voltage
1.25
V
Vdde1v8
DDR2 voltage
1.8
V
vdde3v3
I/O voltage
3.3
V
DDR2_VREF
DDR2 voltage reference
0.9
V
pll_vdd_1
1.0V PLL1 digital voltage
1.2
V
pll_vdd_0
1.0V PLL0 digital voltage
1.2
V
pllio_vdde1v8
1.8V PLL I/O voltage
1.8
V
pll_vdde1v8_1
1.8V PLL1 analog voltage
1.8
V
Pll_vdde1v8_0
1.8V PLL0 analog voltage
1.8
V
pllio_vdd
1.2V PLL I/O voltage
1.2
V
