Electrical characteristics

STLS2F01

38/48

6.3

DC parameters

Table 15.

DC parameters

Parameter

Description

Min

Typ

Max

Unit

Note

VIH

Input high level voltage

(1)

Input pin level (including tri-state pin).

VIL

input low level voltage

0.8

(1)

VOH

output high level voltage

vdde3v3-0.3

(2)

Individual output pin (including output state tri-state pin) level.

VOL

output low level voltage

0.3

(2)

IIH

input high level leakage current

0.002

0.4

µA

(3)

For tri-state input pin (excluding input).

IIL

input low level leakage current

-67.3

-65

µA

(3)

IOL

output low level current

(4)

Individual output pin (including output state tri-state pin) driving capability.

IOH

output high level current

(4)

CIN

Input pin capacitor

4.4

7.5

COUT

Output pin capacitor

RPH

Pull-up resistance

(5)

For input pin (excluding tri-state pin).

Table 16.

DC parameters (JTAG)

Parameter

Description

Min

Typ

Max

Unit

Note

CTIN

Test input capacitance

4.4

7.5

(1)

For TDI, TMS and TRST in JTAG.

CTOUT

Test output capacitance

(2)

For TDO in JTAG.

CTCK

TCK capacitance

4.4

7.5
