STRFNFCA
Example of tag detection command using results of tag detection calibration
Doc ID 023077 Rev 10
61/74
Appendix C
Example of tag detection command using
results of tag detection calibration
The following script works on the evaluation board and with the STRFNFCA developement
software available from the ST internet site.
This is an example of a Tag Detection command when a tag is not present in the RF
operating volume using the STRFNFCA:
>>> 070E0B21007801180020606064743F01
<<< 000101 Wake-up event = Timeout (0x01)
>>> 0803620100
<<< 000101
This is an example of a Tag Detection command when a tag is present in the RF operating
volume using the STRFNFCA:
>>> 070E0B21007801180020606064743F01
<<< 000102 Wake-up event = Tag Detect (0x02)
>>> 0803620100
<<< 000102
