STRFNFCA
Commands
Doc ID 023077 Rev 10
19/74
ISO/IEC 14443
Type B
NFC Forum Tag
Type 4B
0x03
0
7:6
Transmission data rate
00
: 106 Kbps
01
: 212 Kbps
10
: 424 Kbps
11
: 848 Kbps
>>>0x02020301
:
ISO/IEC 14443 Type B tag with
CRC appended
5:4
Reception data rate
00
: 106 Kbps
01
: 212 Kbps
10
: 424 Kbps
11
: 848 Kbps
3:1
RFU
0
Append CRC if set to ‘1’.
(1)
1, 2
AFDT (Optional) 2 bytes
0xPP 0xMM
Set the maximum
STRFNFCA listening time
so that it fits the maximum
ISO FWT:
0xPP
≤0x0E,
0x01
≤0xMM ≤0xFE
Frame Waiting Time (FWT) =
(2PP) *(MM+1) * 4096/13.56 µs
If AFDT is not specified,
the default FWT is ~ 4.8 ms (3)
Table 9.
List of <Parameters> values for the PROTOCOLSELECT command for
different protocols (Reader) (continued)
Protocol
Code
Parameters
Examples of commands
Byte
Bit
Function
