STRFNFCA

Examples of STRFNFCA command code to activate NFC Forum and ISO/IEC 15693

Doc ID 023077 Rev 10

63/74

>>> 09043A005804

<<< 0000

REM,

Recommended modulation and gain is 0xD1 or 0xD3 for NFC Forum

Tag Type 1 (Topaz).

>>> 0904680101D1

<<< 0000

REM, last Byte x7 or x8 in SENDRECV

command

number of bits in the

14443 _Type A

frame

REM,

REQA reply ATQA 000C

>>> 04 02 26 07

<<< 80 05 000C 280000

REM,

RID reply HR0 HR1 UID0 UID 1 UID2 UID3

>>> 04 08 78000000000000 A8

<<< 80 0B 11 48 6E567A00 3E45 080000

REM,

RAll 0408 0000 UID0 UID 1 UID2 UID3 Reply HR0 HR1 UID0 UID 1

UID2 UID3 datas

>>> 04 08 000000 6E567A00 A8

<<< 80 40 11 48 6E567A00

0002250000100E000313D1010F5402656E557365204352393552462021000000000

0000000000000000000000000000000000000000000CCCCCC

REM,

Read ad08 00 UID0 UID 1 UID2 UID3

>>> 04 08 01 0800 6E567A00 A8

<<< 80 07 08 00 87C1 080000

REM,

Write_E ad08

data 12 UID0 UID 1 UID2 UID3

>>> 04 08 53 0812 6E567A00 A8

<<< 80 07 08 12 14F2 080000

REM,

Read ad08 00 UID0 UID 1 UID2 UID3

>>> 04 08 01 0800 6E567A00 A8

<<< 80 07 08 12 14F2 080000

REM,

Write_NE ad08

data A5 UID0 UID 1 UID2 UID3

>>> 04 08 1A 08A5 6E567A00 A8

<<< 80 07 08 B7 B300 080000

REM,

Read ad08 00 UID0 UID 1 UID2 UID3

>>> 04 08 01 0800 6E567A00 A8

<<< 80 07 08 B7 B300 080000

REM,

Write_E ad08

data 00 UID0 UID 1 UID2 UID3

>>> 04 08 53 0800 6E567A00 A8
