Electrical characteristics

ST10F296E

310/346

24.7.5

Example of external network sizing

This section provides an example of how to design an external network, based on realistic

values for the internal parameters and on a hypothesis concerning the characteristics of the

analog signal to be sampled.

The following hypothesis is formulated to design the external network on the ADC input pins:

–

Analog signal source bandwidth (f0):

10 kHz

–

Conversion rate (fC):

25 kHz

–

Sampling time (TS):

1 µs

–

Pin input capacitance (CP1):

5 pF

–

Pin input routing capacitance (CP2):

1 pF

–

Sampling capacitance (CS):

4 pF

–

Maximum input current injection (IINJ):

3 mA

–

Maximum analog source voltage (VAM): 12 V

–

Analog source impedance (RS):

100

Ω

–

Channel switch resistance (RSW):

500

Ω

–

Sampling switch resistance (RAD):

200

Ω

If designing a filter with the pole at the maximum frequency of the signal, the time constant

of the filter is given in Equation 34:

Equation 34

Using the relationship between CF and CS (Equation 33) and taking some margin (4000

instead of 2048), it is possible to define CF as shown in Equation 35.

Equation 35

Equation 34 and Equation 35 allow the RC to be calculated as shown in Equation 36.

Equation 36

Total series resistance can be calculated using Equation 37 where the current injection

limitation is considered and it is assumed that the source can go up to 12 V.

Equation 37

Equation 37 allows a value for RL to be defined as shown in Equation 38.

CCF

πf

()

⁄

15.9

µs

4000

16nF

πf

0CF

()

⁄

995

Ω 1kΩ

≅

INJ

⁄

Ω
