MB96340 Series

Document Number: 002-04579 Rev. *A

Page 4 of 109

Alarm comparator

■ Monitors an external voltage and generates an interrupt in case of a voltage lower or higher than the defined

thresholds

■ Threshold voltages defined externally or generated internally

■ Status is readable, interrupts can be masked separately

I/O Ports

■ Virtually all external pins can be used as general purpose I/O

■ All push-pull outputs (except when used as I2C SDA/SCL line)

■ Bit-wise programmable as input/output or peripheral signal

■ Bit-wise programmable input enable

■ Bit-wise programmable input levels: Automotive / CMOS-Schmitt trigger / TTL (TTL levels not supported

by all devices)

■ Bit-wise programmable pull-up resistor

■ Bit-wise programmable output driving strength for EMI optimization

Packages

■ 100-pin plastic QFP and LQFP

Flash Memory

■ Supports automatic programming, Embedded Algorithm

■ Write/Erase/Erase-Suspend/Resume commands

■ A flag indicating completion of the algorithm

■ Number of erase cycles: 10,000 times

■ Data retention time: 20 years

■ Erase can be performed on each sector individually

■ Sector protection

■ Flash Security feature to protect the content of the Flash

■ Low voltage detection during Flash erase

Feature

Description
