MB96340 Series
Document Number: 002-04579 Rev. *A
Page 74 of 109
14.4.7 Basic Timing
(TA  40°C to 125°C, VCC  5.0 V  10, VSS  0.0 V, IOdrive = 5mA, CL = 50pF)
Parameter
Symbol
Pin
Condition
Value
Unit
Remarks
Min
Max
ECLK
tCYC
ECLK
-
25
-
ns
tCHCL
tCYC/2-5
tCYC/2+5
tCLCH
tCYC/2-5
tCYC/2+5
ECLK →
UBX/ LBX / CSn time
tCHCBH
CSn, UBX, LBX,
ECLK
-
-20
20
ns
tCHCBL
-20
20
tCLCBH
-20
20
tCLCBL
-20
20
ECLK → ALE time
tCHLH
ALE, ECLK
-
-10
10
ns
tCHLL
-10
10
tCLLH
-10
10
tCLLL
-10
10
ECLK →
address valid time
tCHAV
A[23:16], ECLK
-
-15
15
ns
tCLAV
-15
15
tCLADV
AD[15:0], ECLK
-
-15
15
ns
tCHADV
-15
15
ECLK → RDX /WRX time
tCHRWH
RDX, WRX,
WRLX,WRHX,
ECLK
-
-10
10
ns
tCHRWL
-10
10
tCLRWH
-10
10
tCLRWL
-10
10
