background image
MB96340 Series
Document Number: 002-04579 Rev. *A
Page 58 of 109
14. Electrical Characteristics
14.1
Absolute Maximum Ratings
Parameter
Symbol
Rating
Unit
Remarks
Min
Max
Power supply voltage
VCC
VSS - 0.3
VSS + 6.0
V
AVCC
VSS - 0.3
VSS + 6.0
V
VCC = AVCC [1]
AD Converter voltage references
AVRH, AVRL VSS - 0.3
VSS + 6.0
V
AVCC AVRH, AVCC AVRL, AVRH
AVRL, AVRL
 AVSS
Input voltage
VI
VSS - 0.3
VSS + 6.0
V
VI VCC + 0.3V [2]
Output voltage
VO
VSS - 0.3
VSS + 6.0
V
VO VCC + 0.3V [2]
Maximum Clamp Current
ICLAMP
-4.0
+4.0
mA
Applicable to general purposeI/O pins [3]
Total Maximum Clamp Current
|ICLAMP|
-40
mA
Applicable to general purposeI/O pins [3]
“L” level maximum output current
IOL1
-
15
mA
Normal outputs with driving strength set to
5mA
“L” level average output current
IOLAV1
-
5
mA
Normal outputs with driving strength set to
5mA
“L” level maximum overall output current
IOL1
-
100
mA
Normal outputs
“L” level average overall output current
IOLAV1
-
50
mA
Normal outputs
”H” level maximum output current
IOH1
-
-15
mA
Normal outputs with driving strength set to
5mA
”H” level average output current
IOHAV1
-
-5
mA
Normal outputs with driving strength set to
5mA
”H” level maximum overall output current
IOH1
-
-100
mA
Normal outputs
”H” level average overall output current
IOHAV1
-
-50
mA
Normal outputs
Permitted Power dissipation (Flash devices in QFP
package) [4]
PD
-
430[5]
mW
TA=105oC
-
750[5]
mW
TA=90oC
-
540[5]
mW
TA=125oC, no Flash program/erase [6]
Permitted Power dissipation (MB96F346/F347/F348
in LQFP package) [4]
PD
-
375[5]
mW
TA=105oC
-
750[5]
mW
TA=85oC
-
470[5]
mW
TA=125oC, no Flash program/erase [6]
-
560[5]
mW
TA=120oC, no Flash program/erase [6]
Permitted Power dissipation (MB96F345 in LQFP
package) [4]
PD
-
335[5]
mW
TA=105oC
-
670[5]
mW
TA=85oC
-
840[5]
mW
TA=75oC
-
420[5]
mW
TA=125oC, no Flash program/erase [6]
-
590[5]
mW
TA=115oC, no Flash program/erase [6]
