MB96F348CWCPMC-GSE2 데이터시트(PDF) 27 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB96F348CWCPMC-GSE2 데이터시트(HTML) 27 Page - Cypress Semiconductor |
|
|
27 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 27 of 109 000067H RLT1 - Reload Register - for reading R 000068H RLT2 - Timer Control Status Register Low TMCSRL2 TMCSR2 R/W 000069H RLT2 - Timer Control Status Register High TMCSRH2 R/W 00006AH RLT2 - Reload Register - for writing TMRLR2 W 00006AH RLT2 - Reload Register - for reading TMR2 R 00006BH RLT2 - Reload Register - for writing W 00006BH RLT2 - Reload Register - for reading R 00006CH RLT3 - Timer Control Status Register Low TMCSRL3 TMCSR3 R/W 00006DH RLT3 - Timer Control Status Register High TMCSRH3 R/W 00006EH RLT3 - Reload Register - for writing TMRLR3 W 00006EH RLT3 - Reload Register - for reading TMR3 R 00006FH RLT3 - Reload Register - for writing W 00006FH RLT3 - Reload Register - for reading R 000070H RLT6 - Timer Control Status Register Low (dedic. RLT for PPG) TMCSRL6 TMCSR6 R/W 000071H RLT6 - Timer Control Status Register High (dedic. RLT for PPG) TMCSRH6 R/W 000072H RLT6 - Reload Register (dedic. RLT for PPG) - for writing TMRLR6 W 000072H RLT6 - Reload Register (dedic. RLT for PPG) - for reading TMR6 R 000073H RLT6 - Reload Register (dedic. RLT for PPG) - for writing W 000073H RLT6 - Reload Register (dedic. RLT for PPG) - for reading R 000074H PPG3-PPG0 - General Control register 1 Low GCN1L0 GCN10 R/W 000075H PPG3-PPG0 - General Control register 1 High GCN1H0 R/W 000076H PPG3-PPG0 - General Control register 2 Low GCN2L0 GCN20 R/W 000077H PPG3-PPG0 - General Control register 2 High GCN2H0 R/W 000078H PPG0 - Timer register PTMR0 R 000079H PPG0 - Timer register R 00007AH PPG0 - Period setting register PCSR0 W 00007BH PPG0 - Period setting register W 00007CH PPG0 - Duty cycle register PDUT0 W 00007DH PPG0 - Duty cycle register W 00007EH PPG0 - Control status register Low PCNL0 PCN0 R/W 00007FH PPG0 - Control status register High PCNH0 R/W 000080H PPG1 - Timer register PTMR1 R Table 4: I/O map MB96(F)34x Address Register Abbreviation 8-bit access Abbreviation 16-bit access Access |
|
